Fuji Smart power device M-POWER2
for Multi Multi-oscillated current resonant type power supply
- High efficiency (a reduction in SMPS size is possible.) DC/DC: 92.3%(DC input:400V,output:16V) PFC+DC/DC:87.0%(AC100V),89.5%(AC200V)
- Built in stand-by mode (An auxiliary power supply is unnecessary.) Pin<0.4W at Pout=0.0, Pin<1.0W at Pout=0.5W, Pin<4.0W at Pout=2.0W
- Low noise (a reduction in the noise suppression parts is possible.) MOSFETs：Turn-on : ZVS+ZCS Turn-off : ZVS Diodes(secondary side) Surge voltage does not occur at reverse recovery.
- Fail-safety (Built in protection functions:OC,SC,OV,Tj(OH))
- Easy design power supply (Reduction of design time)
